706-753/300-200
Product ID:42305
Updated: 2026/7/13
Key Features
- 114-pole pluggable connectors per DIN 41651
- 22-meter length for versatile connectivity
- 3Conductor cross-section: 0.14 mm² for reliable current transmission
- 4Rated for a current of 1A per conductor
- 5IP20 protection rating for safe operation
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Note | When using more than 10 wires, the maximum current per wire must be reduced to 0.7?A. | Operating voltage | ≤35?VDC |
| Current per wire (max.) | 1A | Cable type | LiYY |
| Color code | per DIN VDE 47100 | Cable length | 2m |
| Weight | 114g | Ambient temperature (operation) | -25 … +70 °C |
| Product Group | 30 (WAGO France) | eCl@ss 10.0 | 27-06-03-11 |
| eCl@ss 9.0 | 27-06-03-11 | ETIM 9.0 | EC001855 |
| ETIM 8.0 | EC001855 | ECCN | NO US CLASSIFICATION |
| PU (SPU) | 1?pcs | Packaging type | box |
| Country of origin | FR | GTIN | 4050821038863 |
| Customs tariff number | 8544429090 | RoHS Compliance Status | Compliant,No Exemption |
| Pluggable connector | Pluggable connector per DIN 41651; female connector | Pole number 1 | 14 |
| Connection type 1 | System | Wire cross-section | 0.14mm2 |
| Connector 2 | Pluggable connector per DIN 41651; female connector | Pole number (2) | 14 |
| Connection type 2 | System |
Specifications may be subject to change without notice
