806-912
Product ID:38816
Updated: 2026/7/13
Key Features
- 1Reliable Electrical Connectivity: Ensures secure and stable connections in industrial applications.
- 2Efficient Design: Straight THT pin strip with 12 poles and 5mm pin spacing for easy integration.
- 3High-Quality Materials: 1mm solder pin diameter and 3.4mm solder pin length for durable connections.
- 4Easy Installation: Black color and straightforward design simplify the installation process.
- 5Rohs Compliant: Meets RoHS compliance standards for environmental safety and regulatory requirements.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Number of levels | 1 | Pin spacing | 5?mm?/ 0.197?inches |
| Width | 59.8?mm?/ 2.354?inches | Height | 12?mm?/ 0.472?inches |
| Depth | 2.7?mm?/ 0.106?inches | Solder pin length | 3.4mm |
| Solder pin diameter | 1mm | Drilled hole diameter with tolerance | 1.3(+0.05)mm |
| Suitable | Pin spacing: 5 mm / 0.197 inch | Contact type (pluggable connector) | Male connector/plug |
| Connector (connection type) | for PCB | Mating direction to the PCB | 90° |
| PCB contact | THT | Note (material data) | Information on material specifications can be found here |
| Color | black | Insulation material (main housing) | Polyamide (PA46) |
| Flammability class per UL94 | V2 | Weight | 1.7g |
| Product Group | 4 (Printed Circuit Connectors) | eCl@ss 10.0 | 27-14-11-92 |
| eCl@ss 9.0 | 27-14-11-92 | ETIM 9.0 | EC002848 |
| ETIM 8.0 | EC002848 | ECCN | NO US CLASSIFICATION |
| PU (SPU) | 100?pcs | Packaging type | box |
| Country of origin | DE | GTIN | 4044918429252 |
| Customs tariff number | 8536908585 | RoHS Compliance Status | Compliant,No Exemption |
| Number of poles | 12 |
Specifications may be subject to change without notice
