811-431
Product ID:49475
Updated: 2026/7/13
Key Features
- 1Compact Design: Fits DIN-rail 35 x 15 and 35 x 7.5 for space-efficient installations.
- 2Blown Fuse Indication: Visual confirmation of fuse status ensures quick troubleshooting.
- 3High Voltage Compatibility: Supports up to 600 VAC/VDC for robust electrical connections.
- 4CAGE CLAMP Technology: Secure and reliable clamping system for conductors up to 16 mm².
- 5Durable Construction: Built to withstand harsh industrial environments with minimal maintenance.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Safety information | The fuse holder must not be opened under load. | Clamping units | 6 |
| Total number of potentials | 3 | Number of levels | 1 |
| Width | 52.5?mm?/ 2.067?inches | Height | 105?mm?/ 4.134?inches |
| Depth from upper-edge of DIN-rail | 55?mm?/ 2.165?inches | Mounting type | DIN-35 rail |
| Mounting (note) | The fixed foot of the fuse terminal block must face upwards so that the fuse cannot fall out. | Note (material data) | Information on material specifications can be found here |
| Color | light gray | Material group | I |
| Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
| Weight | 1.1g | Processing temperature | -35 … +85?°C |
| Continuous operating temperature | -35 … +85?°C | Product Group | 1 (Rail Mounted Terminal Blocks) |
| eCl@ss 10.0 | 27-14-11-16 | eCl@ss 9.0 | 27-14-11-16 |
| ETIM 9.0 | EC002705 | ETIM 8.0 | EC002705 |
| ECCN | NO US CLASSIFICATION | PU (SPU) | 4?(1)?pcs |
| Packaging type | box | Country of origin | CN |
| GTIN | 4055143187442 | Customs tariff number | 8536904000 |
| RoHS Compliance Status | Compliant,No Exemption | Ratings per | IEC/HD 60269-2 |
| Rated voltage (III / 3) | 600V | Rated current | 30A |
| Blown fuse indication | with blown fuse indication | Ratings (note) | Electrical ratings are specified in the technical data of both fuse terminal block and fuse. When selecting glass cartridge fuses, make sure that the listed power loss is not exceeded. |
| Rated voltage (III/3) 2 | 600V | Approvals per | CSA 22.2 |
| Rated voltage (UL) | 750V | Rated current UL | 30A |
| Rated voltage (UL 2) | 1,000V | Rated current (CSA) | 30A |
| Rated voltage (CSA) | 600V | Rated voltage CSA 2 | 600V |
| Power loss P<sub>l</sub> max. overload and short-circuit protection (individual arrangement) | 3W | Power loss P<sub>l</sub> max. overload and short-circuit protection (group arrangement) | 3W |
| Power loss P<sub>l</sub> max. short-circuit protection (individual arrangement) | 3W | Power loss P<sub>l</sub> max. short-circuit protection (group arrangement) | 3W |
| Voltage type 1 | AC | Voltage type 2 | DC |
| Fuse receptacle | pluggable | Fuse type | Cylindrical fuse; 10 x 38 mm; Class CC |
| Connection technology | CAGE CLAMP? | Actuation type | Operating tool |
| Connectable conductor materials | Copper | Solid conductor | 2.5 … 16?mm2?/ 14 … 6?AWG |
| Fine-stranded conductor | 2.5 … 16?mm2?/ 16 … 6?AWG | Strip length | 12 … 13?mm?/ 0.47 … 0.51?inches |
| Number of poles | 3 | Wiring direction | Side-entry wiring |
Specifications may be subject to change without notice
