855-4005/150-101
Product ID:40278
Updated: 2026/7/13
Key Features
- 1Ideal for use in very confined spaces.
- 2Current ratios from 150 A (primary side) and 5 A (secondary side).
- 3Compact and hinged design with rapid mounting.
- 4No primary cable interruption during installation.
- 5Accuracy Class 1 with a maximum burden of 1 VA.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Protection type | IP20 | Test voltage | AC 3?kV;?50?Hz;?1?min |
| Highest voltage for equipment U<sub>m</sub> | AC 720?Vrms | Feedthrough for measurement conductor | ? 18 mm |
| Cable type | 2 x 1.5 mm2; fine-stranded | Color code | black = S1; red = S2 |
| Cable length | 0.5m | Width | 57.2 mm / 2.25 inches |
| Height | 67 mm / 2.64 inches | Depth | 49 mm / 1.93 inches |
| Mounting type | Split-core current transformer (suspended) | Weight | 341g |
| Ambient temperature (operation) | -10 … +55 °C | Ambient temperature (storage) | -20 … +70 °C |
| Relative humidity | 5 … 85?% (without condensation) | Operating altitude (max.) | 2000m |
| Conformity marking | CE | Standards/specifications | EN 61869-1 |
| Product Group | 29 (INTERFACE ELECTRONIC (NET)) | eCl@ss 10.0 | 27-21-09-02 |
| eCl@ss 9.0 | 27-21-09-02 | ETIM 9.0 | EC002048 |
| ETIM 8.0 | EC002048 | ECCN | NO US CLASSIFICATION |
| PU (SPU) | 1?pcs | Packaging type | Box |
| Country of origin | NL | Customs tariff number | 85043180888 |
| RoHS Compliance Status | Compliant,No Exemption | Measured variable | Current |
| Rated continuous thermal current I<sub>cth</sub> | 100 % | Rated short-time thermal current I<sub>th</sub> | 60 x IN/ 1 s |
| Rated surge current I<sub>dyn</sub> | 2.5 x Ith | Rated frequency | 50 … 60?Hz |
| Primary rated current | 150?A | Secondary rated current | 5A |
| Rated power S<sub>r</sub> | 1VA | Accuracy class | 1 |
Specifications may be subject to change without notice
